Airflow charts

Rack Airflow Visualized

Quickly visualize a complete history of airflow data from any rack and gain insights into trends and problems. Additionally, data can be exported for further analysis.

Airflow chart for a rack across 24 hours, with the hover readout showing ACH and DP at the selected time

A brief demonstration

Below is a quick demonstration of the chart features in RackNet.

Click on any rack to view the rack details page, then click on the “History” tab to view the chart
Click on the “Live Data” tab to return to the most recent airflow values received from a rack
Visually see any change in airflow (from 50 ACH to 80 ACH here)
Mouse over any data point to see all values for that time
Zoom in and out, as well as pan right or left
Download data as an image (PNG, SVG) or CSV (then import into a spreadsheet)
Live updates as new data arrives
- At 00:48 in the video, notice “waiting for data…” appears
- The rack sent new airflow data to RackNet
- As data is updated, the most recent time changes
